| Display Technology |
3LCD Panels x 0.75" SONY |
| Native Resolution |
WXGA / Native 1280 x 800 Pixels Original resolution_8000U series |
| Max. Computer Input |
WUXGA / Native 1920 x 1200 Pixels |
| Brightness |
13,000 ansi Lumens |
| Contrast |
4000:1 Contrast Ratio,Dynamic Video contrast ratio up to 10000:1 by HDMI |
| Fan Noise |
As low as 31 dBa |
| Aspect Ratio |
4:3 Native, 16:9Compatible |
| Projection Method |
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip |
| Weight |
15 kg |
| I/O Connectors |
Inputs: |
HDMI,MHL,computer1,2,S-video,BNC,Audio in 1,Audio in 2,LAN,USB-A,USB-B,mini-USB,Monitor out,Audio out,RS232 |
| Computer Compatibility |
Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac… |
| Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p) |
| Displayable Colours |
1.07 Billion |
| Projection Lens |
Standard lens: |
F = 1.8 - 2.6, f = 24.0 - 43.2mm, 1.8x, Vertical: ±60° (Powered) Horizontal: ±30° (Powered) |
| Power Lens Shift: |
U/D 50%; L/R 10% |
| Lens Optional: |
Short throw lens,Long throw lens,Ultra-short focal-lens,360-degree wide-angle lens,Spherical Fisheye lens |
| Throw Ratio |
1.44 - 2.60 : 1 |
| Projection Screen Size |
40” - 300” |
| Projection Distance |
0.6m - 46.5m (Depanding on optional lenses) |
| Lamp Type/Lamp Life |
500W single lamp, 6000/5000 hours (ECO/BRIGHT mode) |
| Keystone Correction * |
Vertical: ±15° (Auto/Manual) Horizontal: ±15° (Manual), Corner Keystone |
| Dimensions (W x D x H) |
48.0cm x 18.0cm x 42.0 cm (18.8” x 7.0” x 16.5”) |
| Remote Control |
Full function remote with direct source selecting,wifi, LAN |
| Power Supply |
100-240V, 50-60Hz |
| Power Consumption |
600W BRIGHT mode <5W Standby mode, 550W STD mode < 1W Standby mode |
| Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
| Uniformity |
90% |
| Security |
Kensington Lock, Password Protection |
| Standard Accessories |
AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card |
| Optional Accessories |
Ceiling Mount Kit, Additional Ultra long Cable |
| Warranty |
Projector 5-Years,lamp six months or 500Hrs |
|
