| Model |
CVDP9170
|
| |
|
| Display Technology |
DLP DMD 0.67 |
| Native Resolution |
WUXGA 1920* 1200 |
| Max. Video Input |
4K input |
| Brightness |
9,000 ansi Lumens |
| Contrast |
100000:1 Contrast Ratio |
| Fan Noise |
As low as 27 dBa |
| Aspect Ratio |
16:10 Native,16:9 Compatible |
| Projection Method |
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip |
| Weight |
12 kg |
| I/O Connectors |
HDMI⑤x2; DVIx1; VGA Inputx1; HDBaseTx1; VGA Outputx1; RS232x1 RJ45x1Inputs:,3D sync*1 |
| Maximum Resolution |
4K via HDMI Terminal |
| Computer Compatibility |
Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac… |
| Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p) |
| Displayable Colours |
1.07 Billion |
| Projection Lens |
0 .34:1,0.42:1,0.56:1, 0.79:1, 0.79-1.0:1
0.99-1.26:1
1.26-1.58:1 (STD)
1.58-3.0:1 3.0-5.7:1 |
| Projection Screen Size |
100" at 2.94m |
| Projection Distance |
1.025-25.48m(Standard Power Lens ) |
| Lamp Type/Lamp Life |
500W Roller type laser light source, 20000 hours life
|
| lens shift |
± 100° Vertical ± 30° Horizontal remote control |
| keyston correction |
V+H |
| Dimensions (W x D x H) |
486x393x174mm |
| Remote Control |
Full function remote with direct source selecting |
| Power Supply |
100-240V, 50-60Hz |
| Power Consumption |
580W |
| Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
| Uniformity |
90% |
| Standard Accessories |
AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card |
| Optional Accessories |
Ceiling Mount Kit, Additional Ultra long Cable |
| Guarantee |
Projector 5-Years,lamp six months or 500Hrs |
|
